power angle plow
I'm looking to start putting together a power angle plow. I was wondering if the controls on the tractor would work instead of buying another valve. I have the diverter valve and was hoping to use it for the power angle plow. Any ideas would be great "in theory" this is a good idea but how many times do we have a great idea and they just don't work the way we hoped!
-
- Team Cub Mentor
- Posts: 20336
- Joined: Fri Jul 02, 2004 9:52 pm
- Zip Code: 65051
- Circle of Safety: Y
- Location: Mo. Linn
Re: power angle plow
The major problem adding a power angle plow is that entire 185's hydraulic system is that it's one way, except for the hydraulic pump. You will need to convert all or part of the hydraulic system to 2 way hydraulics to operate/change the angle of the plow blade.
There are several different components/configurations to the numbered cubs hydraulic system. Suggest obtaining the parts and service manual then removing sheet metal to determine exactly which configuration you have.
I would study the current hydraulic system on your Cub, make a list of needed parts and parts prices before spending any money.
There are several different components/configurations to the numbered cubs hydraulic system. Suggest obtaining the parts and service manual then removing sheet metal to determine exactly which configuration you have.
I would study the current hydraulic system on your Cub, make a list of needed parts and parts prices before spending any money.
I have an excuse. CRS.
- SONNY
- 10+ Years
- Posts: 4086
- Joined: Thu Nov 09, 2006 11:26 pm
- Zip Code: 61722
Re: power angle plow
You could go with an ele.over hyd lift ,if you have one laying around.---I ended up with several of them over the years and never tossed them in the trash! thanks; sonny
- gitractorman
- 10+ Years
- Posts: 2678
- Joined: Mon Oct 24, 2005 11:35 am
- Zip Code: 14072
- eBay ID: toysforjake
- Tractors Owned: Lots of Cub Cadets!
1951 Farmall Cub
1977 IH Cub
1966 IH Cub
1965 IH Lo Boy
1964 IH Lo Boy
1949 Farmall Cub
Several IH 154 Lo Boys
1979 IH 184 Lo Boy
Simplicity 4416 Sovereign
Simplicity Conquest
Simplicity Legacy 4x4 Diesel
Mitsubishi MT180D 4x4 Diesel - Circle of Safety: Y
- Location: Grand Island, NY
Re: power angle plow
I actually started putting together a parts diagram to make a lever actuated angling mechanism like is used on Wheel Horse garden tractor snow plows. The blade pivots easy when raised off the ground, so a handle (like pistol grip) lever to pull a pin, and then allow you to pull/push an arm lever, would easily turn the plow. The Wheel Horse plows work great, and it's a super simple design.
This photo shows the lever on a Wheel Horse plow that pivots the blade. The little silver hand lever is what pulls the locking pin, then the whole arm moves to angle the blade. The blade is raised/lowered by the whole frame lifting, which pivots on the back axle hanger bracket, so the whole thing is quite sturdy.
In this image you can see where the arm attaches to angle the plow.
Sure a lot simpler than hydraulics!!!
This photo shows the lever on a Wheel Horse plow that pivots the blade. The little silver hand lever is what pulls the locking pin, then the whole arm moves to angle the blade. The blade is raised/lowered by the whole frame lifting, which pivots on the back axle hanger bracket, so the whole thing is quite sturdy.
In this image you can see where the arm attaches to angle the plow.
Sure a lot simpler than hydraulics!!!
Cub Cadets 682, 1811, 1864, Simplicity Legacy XL 4x4 Diesel with FEL, 60" mower, 50" Tiller
-
- 10+ Years
- Posts: 7388
- Joined: Sat Jul 22, 2006 5:02 pm
- Zip Code: 00000
- Location: in northern usa
Re: power angle plow
To add another control valve just take the return line and run it to the second valve. Mount the valve on the outside and make a mirror image to the up n down lever. Using the selector valve is a pain for turning the plow.
I'm technically misunderstood at times i guess its been this way my whole life so why should it change now.
