Re: First Cub Clutch Job - Where to Start?

Postby oldiron1 » Sat Apr 27, 2013 11:14 pm

Good News and Bad News I guess:

After an afternoon of adjusting, I got all 3 fingers where they need to be and adjusted the clutch pedal as well. While it's a little better, the grinding is still there I'm I'm not totally sure why.....the TOB seems to have a lot of meat left on it, fingers are adjusted, pedal is adjusted and when I pull the pedal by hand, I can clearly see the TOB pushing against the fingers and the pressure plate being pulled back taking the pressure off of the disk.

The only thing that doesn't look quite right to me is all of the knicks in the TOB. When I start the engine up and proceed to push the clutch pedal in, I can hear and feel the clutch chatter,but then when I continue to push the pedal further, the chatter goes away. When looking from the bottom, I can tell that the TOB isn't quite centered on the fingers as Rick advised to look for....by hand, I can move the TOB hanger both ways slightly. Is there a way / how can I tighten up the hanger? Is there a way to tighten the hanger from the bottom through the inspection hole?

Although, the adjusting today didn't result as well as I was hoping, it was a beautiful day outside today and still felt great to take Lydia for a ride around the block. :D
oldiron1
501 Club
501 Club

Posts: 815
Joined: Mon Jul 23, 2007 10:12 pm
Location: Oconomowoc, WI
Zip Code: 53066
eBay ID: smalltownusa609
Tractors Owned: -
(2) LoBoy's:
'55 w/ Fast Hitch & Tach
'64 "Modified" LoBoy Train

(4) F-Cubs including:
'49 Non-Electric Cub
'50 Demo Cub
'50 Hi-Clearance w/ Wide Package
'57 French Cub with 2-Way Molboard Plows

A Few Cub Cadets

Re: First Cub Clutch Job - Where to Start?

Postby Denny Clayton » Sun Apr 28, 2013 7:31 am

Rob, a couple more things you might try. Engage the pto lever and see if the drag of the transmission slows the shaft down. Also, your shaft may be dragging with the pilot bushing. Tape a couple squirt straws together from your favorite penetrant/lube. Reach the straws up in front of your pressure plate and get some spray up toward the pilot bushing. It was a good cure for one of mine.
'61 Lo-Boy
'60 FH Lo-Boy
'60 Lo-Boy
'57 FH Cub "Rusty"
'56 FH Cub
(2) '48 Cubs
'75 IH 140 w/1000 loader
C-3 mower, FH Woods 42F, 22 sickle (2), 54A blade, L-54 blade, 194 plow, FH L-38 disk, FH LB disk, 144 cultivators, FH platform carrier
User avatar
Denny Clayton
501 Club
501 Club

Posts: 3588
Joined: Wed Feb 05, 2003 1:18 pm
Location: OH, Sidney
Zip Code: 45365
Tractors Owned: Home to "Rusty", the 2007 and 2009 Cub Tug Champion.
Circle of Safety Award
Circle of Safety: Y

Re: First Cub Clutch Job - Where to Start?

Postby oldiron1 » Sun Apr 28, 2013 10:47 pm

Thanks Denny, I really appreciate the suggestions; both I'll try.
